7″ OpenVario Kit (without Sensor Board)


7″ OpenVario kit with housing and electronics. At least one Input Device is required for operation. By installing the optionally available Sensor Board , the OpenVario works as a full electronic variometer as well.

  • black anodized aluminum body, display frame and backplate
  • electronics completely assembled and tested (incl. display and Cubieboard2)
  • display cable, screws and mounting material
  • D-Sub 15 solder connector for connecting to the on-board power supply and speaker (aviation wire and speaker not included)
  • 4GB Micro SD card with adapter

Delivery time: 3 - 5 business days

Out of stock

SKU: SFOV-7-K2 Category:

More space for the essentials - with the 7'' SteFly OpenVario

With the SteFly OpenVario in the 7" version, you always have an overview thanks to the large and very bright 1000 cd/m² display.

Technical Data
Display: 7'', resolution 800 x 480 px
Display brightness: 1000 cd/m²
CPU: DualCore 1,2 GHz
Input voltage range: 9 to 16 V
Amperage: 490 mA @ 12,9 V
Interfaces: 3 serial interfaces e.g. for connecting Flarm, radio or external vario (2 x RJ45 IGC pin assignment, 1 x D-Sub 15 pin)
USB: 2 USB-A ports, extendable with USB hub
Operating Temperature: -30°C to +60°C
Dimensions: 170,8 x 112,2 x 85 mm; see drawing for panel cutout below
Weight: 530 g
Material: black anodized aluminum body, display frame and backplate
External fuse: 3 A
Recommended Accessories: USB-A panel mount adapter (for quick updates) and on/off switch on the instrument panel

To get an overview of the steps required to complete the kit, please take a look at the following instructions: https://www.stefly.aero/assembly/

The time required for assembly is approx. 30 - 60 minutes.
